DrayTek Vigor166 G.fast / VDSL2 Modem Router

Upgrade your broadband infrastructure with the DrayTek Vigor166, an advanced G.fast and VDSL2 35b super vectoring modem router engineered for small offices and residential deployments. Eliminating the need for separate standalone modems, the Vigor166 integrates a high-speed DSL WAN port with dual gigabit Ethernet LAN ports to deliver downstream speeds of up to 300 Mbps and upstream speeds of up to 100 Mbps. Configurable as either a dedicated bridge or a robust firewall router, it provides the ultimate foundation for high-bandwidth multi-play applications.

DrayTek Vigor166 Physical Interfaces and Port Layout

Designed for straightforward integration into your network infrastructure, the Vigor166 features an intuitive rear panel layout that clearly separates your broadband connection from wired client equipment and power management.

Ultra-Fast G.fast and Super Vectoring Performance

Unlock ultrafast fibre-to-the-cabinet (FTTC) and G.fast broadband capabilities. The Vigor166 provides comprehensive support for ITU-T G.fast technology alongside VDSL2 profiles up to 35b Super Vectoring, ensuring your network handles data-intensive cloud computing, high-definition video streaming, and VoIP telephony without lag or bottlenecks.

Multi-PVC and VLAN Support for Triple-Play Services

Optimise network traffic separation across your office environment. Featuring support for multiple PVCs and VLANs (up to 5 profiles), the modem router seamlessly prioritises data, IPTV video streams, and VoIP voice packets to guarantee uninterrupted transmission for business-critical operations.

Comprehensive Content Security Management and Firewall

Safeguard your local network against emerging digital threats. Built with an enterprise-grade Stateful Packet Inspection (SPI) firewall, the Vigor166 offers advanced DoS attack defence, custom port-forwarding rules, Layer 3 packet filtering, and HTTP content filtering by URL keyword and web feature blocking.

Flexible Bridge or Router Operation with Professional Management

Adapt the device instantly to your network architecture by toggling between router and bridge operating modes. Network administrators can easily configure and monitor fleets using the intuitive web-based user interface, Command Line Interface (CLI via Telnet/SSH), or TR-069 remote management integrated with VigorACS 2.

Features

• ITU-T G.fast Compliance - Designed for next-generation ultrafast copper broadband lines
• VDSL2 Super Vectoring (35b) - Maximises line rates over existing copper infrastructure
• SPI Firewall Protection - Defends local area networks against malicious traffic flooding and unauthorised access
• TR-069 Centralised Management - Fully compatible with DrayTek VigorACS 2 for streamlined remote provisioning and diagnostics
• Syslog E-Mail Alerts - Automated logging and alert notifications for proactive network monitoring
• Compact Residential & SOHO Design - Space-saving footprint engineered for reliable, continuous operation

Technical Specifications

Product Model

• DrayTek Vigor166 G.fast / VDSL2 35b Modem/Router

WAN Interface

• 1x RJ11 DSL Port (Supports G.fast, VDSL2 35b Super Vectoring, ADSL2+)

LAN Interface

• 2x 10/100/1000Base-TX RJ-45 Ethernet LAN Ports

Physical Buttons

• 1 x Factory Reset Button

DSL Compliance

• ITU-T G.993.2 (VDSL2), ITU-T G.993.1, G.997.1, G.fast

Network Features

• Router/Bridge configurable, IGMP Proxy v2/v3, DHCP Client/Relay/Server, Dynamic DNS, UPnP (100 Sessions)

Firewall & Security

• NAT, DMZ Host, Port-redirection, MAC Address Filter, SPI Firewall, DoS Prevention, E-Mail Alert and Logging via Syslog, VPN Pass-Through (IPsec, PPTP, L2TP)

Content Security Management

• URL Keyword Filter (Whitelist/Blacklist), File Blocking (Java, Cookies, ActiveX, Multimedia)

Management Protocols

• Web-based UI (HTTP/HTTPS), CLI (Telnet/SSH), SNMP v1/v2c, TR-069 / VigorACS 2

Package Contents

• DrayTek Vigor166 Modem/Router
• Ethernet Cable
• RJ11 DSL Cable
• Power Adapter
• Quick Start Guide
