Draytek Vigor 167-K 35b VDSL2/ADSL Modem & Ethernet Router

About the Draytek Vigor 167

The Vigor167 is a VDSL2 35b Modem / Router that delivers download speeds up to 300 Mbps. It is equipped with one RJ-11 Port and Two GbE LAN Ports, and is backward compatible with ADSL2+. The Vigor167 is also Router / Modem (bridge) configurable and supports TR-069, which allows it to be managed by VigorACS3 for zero-touch deployment and remote management.

The Vigor167 is the perfect solution for businesses and homes that need a reliable and fast internet connection. It is easy to set up and use, and it offers a number of features that make it ideal for a variety of applications.

Features

• VDSL2 & ADSL2+ to Ethernet Modem
• Two Gigabit LAN Ports
• No Set-Up Needed, Wall Mountable
• Up to 300 Mbps Download Speed
• Add DSL Connectivity to any Router
• Pre-Configured to Work with most ISP's
• Supports ADSL/ADSL2/ADSL2+/VDSL/VDSL2

Interface

• WAN Port - 1x RJ-11 for VDSL2 35b/ADSL2+
• LAN Port - 2x Gigabit Ethernet RJ-45

Performance

• Max VDSL Speed - 300 Mbps
• Max ADSL Speed - 20 Mbps
• NAT Sessions - 10,000

DSL

• VDSL Standards - ITU-T G.993.1 (VDSL), G.997.1, G.993.2 (VDSL2)
• VDSL2 Profile - 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a, 35b (not G.fast)
• VDSL Band Plan - 997, 998
• ADSL Standards - ANSI T1.413, ITU-T G.992.1(G.dmt)
• ADSL2 Standards - ITU-T G.992.3, G.992.3 Annex M/J
• ADSL2+ Standards - ITU-T G.992.5, G.992.5 Annex M/J

Internet Connection

• IPv4 - PPPoE, DHCP, Static IP, PPTP/L2TP
• IPv6 - PPP, DHCPv6, Static IPv6, TSPC, 6rd, 6in4

Networking

• Routing - IPv4 Static Routing, IPv6 Static Routing, RIP v1/v2
• IGMP - IGMP v2/v3, IGMP Proxy, IGMP Snooping

LAN

• Number of LAN Subnet - 1
• Virtual Routing Interface - 1
• Bind-IP-to-MAC - IPv4 Only
• DHCP Server - Custom DHCP Options, IPv4/IPv6 DHCP Server, IPv4/IPv6 DHCP Relay
• IPv6 Address Assignment - DHCPv6, RADVD

Firewall

• NAT - Port Redirection, Open Ports, DMZ Host, UPnP
• ALG - SiP, RTSP
• VPN Pass Through - PPtp, L2TP, IPsec

Management

• Local Service - HTTP, HTTPS, Telnet, SSH v2, TR-069
• Firmware Upgrade - TFTP, HTTP, TR-069
• Access Control - Access List
• Notification Alert - E-Mail
